LOWER CONTROL ARMS
STOCK WIDTH OR 5/8" NARROWED, TABS FOR SWAY BAR THAT MOUNTS BEHIND CROSS MEMBER ARE INCLUDED
GAYLECO
Gayle Bridges Company
212 Davis Drive
Hot Springs, AR 71901
Phone: 501-321-1130 or 501-617-2584
Fax: 501-321-1470
E-Mail: gayle.bridges@cablelynx.com
SELECTING CONTROL ARMS, SPRINGS, & SHOCKS FOR INDEPENDENT
FRONT SUSPENSION MUSTANG II CONVERSION
Upper & Lower Control Arms - Stock or Tubular - Stock Lower Arms Requires Strut Rods - Tubular Lower Arms are Normally
Strutless
Springs - Stock or Coil-Over, ( Coil-Over 8", 10" 12" or 14" long, 10" utilizes 4" stroke shock for a better ride & 12"/14" utilizes 4
1/2" Stroke for the BEST Ride. )
Shocks - Stock 2.6" stroke, Pro Stock OEM Replacement 3.3" stroke, Coil-Over 4" or 4.5" stroke ( Non Adjust, Steel, Non Adjust.
Aluminum or Adjust Aluminum )
The 10" spring & 4" stroke shock utilizes Lower Control Arms with the Coil-Over mounting 1" below stock location.
The 12" Spring & 4" Stroke Shock  utilizes Lower Control Arms with the Coil-Over Mounting 1 3/4" below stock location.
The 14" spring & 4 1/2" stroke shock utilizes Lower Control Arms with the Coil-Over mounting  2 1/2" below stock location.
A Good Rule of Thumb for the Ride Height of Shocks is Compressed Lenght Plus 60% of Stroke with the Lower Control
Arm Level.
Since the Stroke of the Shock Mustang II Shock is short the Ride Height of the Shock needs to be held pretty close to the Rule so as
not to bottom out the Stock Shock on compression or extension.
****Conversions are set-up for 50% to 60% of the Shock Stroke ( rod  showing ) with the Lower Control Arms Level.
Hosting by Yahoo! Web Hosting
                                 Choice Between Tappered or Wide Pattern
                               Standard  or Narrowed 5/8" is determined by
                               needed Hub to Hub Dimension. See Hub to
                              Hub Dimension Chart  for the dimension that
                                                Matches Your Vehicle.
Stock Spring & Shock
Mount Location
Coil-Over Mount 1"
Below Stock Location
Coil-Over Mount 2 1/2" &1 3/4"
Below Stock Location  2 1/2" Shown

STOCK SPRINGS & SHOCKS
COIL-OVER SPRINGS & SHOCKS
8" Normally
Used by Other
Suppliers But
Will Provide A
"Very Firm
Ride".
Plated Steel
Aluminum
Aluminum
PlatedSteel
Aluminum

Stock Shocks, 2.6"
Stroke, 10.7" Mount
Height
Replacement Stock,
3.3" Stroke, 10.7"
Mount Height,
**Height with 80%
Showing
Non Adjustable
Adjustable
Non Adjustable
Adjustable
4" Stroke, 11.4" Mount Height with 80%
Showing
4 1/2" Stroke, 13.2" Mount Height with 50%
Showing
Chrome
Plated
Black Painted
Black Paint or Powder Coated
13" High Spring
8" High Spring          10" High Spring
12" High Spring
14" High Spring
